The fully automatic case erector CE-31 guarantees perfectly rectangular cases, which is required to obtain a controlled and trouble-free packaging process.

The box erecting machine automatically forms cardboard boxes with length up to 730 mm. Standard in hot melt execution, but also available in tape. By using hot melt to close the bottom flaps, the carton erector enables a continuous production, low running cost and a stable case transport.

With easy format changeover and features to accommodate poor corrugated cartons, this case erector is a solid addition to your packaging line.

Hot melt: standard up to 16 c/min.
Tape: standard up to 12 c/min, upgradeable to 16 c/min.

The CC-31 automatically folds the top case flaps and closes them with tape.

To save floor space and maximize operator convenience, the case closing machine with related software is standard integrated in the bag closer, visualizing all messages on one HMI. The stand-alone case closer with separate 15” HMI is available as an option.

Equipped with an in- and outfeed guarding, multicolour warning light and adjustable box pressing before taping, the CC-31 reaches a high speed of up to 18 c/min.

The DS-21-HE automatically decuffs, stretches and heat seals the bag, using double sided impulse heat sealing.

With its typical features such as hermetic heat sealing, vacuumizing, gas flushing, high level of cleanability and crate handling, this bag sealing machine meets the needs of the high demanding industries.

The DS-21-HE standard handles one case footprint with variable heights. Upgradeable to multi case footprint.

Depending on the application, the bag heat sealer runs up to 10 c/min without vacuum nor gas flush installation.

Designed for maximum flexibility, the high performance Flexim-41 makes and inserts made-to-measure bags into cardboard boxes, (EPS) crates and trays.

Starting from a parent film roll, you obtain the best price per bag and benefit from the most hygienic packaging.The machine is equipped with fully automatic format change and runs up 22 c/min.

Combine the Flexim-41 bag inserter with a Pattyn case erector, bag closer, case closer and palletizer to profit from a fully automated meat packaging line.

The fully automatic case erector CE-31 guarantees perfectly rectangular cases, which is required to obtain a controlled and trouble-free packaging process.

The box erecting machine automatically forms cardboard boxes with length up to 730 mm. Standard in hot melt execution, but also available in tape. By using hot melt to close the bottom flaps, the carton erector enables a continuous production, low running cost and a stable case transport.

With easy format changeover and features to accommodate poor corrugated cartons, this case erector is a solid addition to your packaging line.

Hot melt: standard up to 16 c/min.
Tape: standard up to 12 c/min, upgradeable to 16 c/min.

The CC-31 automatically folds the top case flaps and closes them with tape.

To save floor space and maximize operator convenience, the case closing machine with related software is standard integrated in the bag closer, visualizing all messages on one HMI. The stand-alone case closer with separate 15” HMI is available as an option.

Equipped with an in- and outfeed guarding, multicolour warning light and adjustable box pressing before taping, the CC-31 reaches a high speed of up to 18 c/min.

The DS-21-HE automatically decuffs, stretches and heat seals the bag, using double sided impulse heat sealing.

With its typical features such as hermetic heat sealing, vacuumizing, gas flushing, high level of cleanability and crate handling, this bag sealing machine meets the needs of the high demanding industries.

The DS-21-HE standard handles one case footprint with variable heights. Upgradeable to multi case footprint.

Depending on the application, the bag heat sealer runs up to 10 c/min without vacuum nor gas flush installation.
