Collecting data with TLC 750 BT and EDC

The thermometer TLC 750 BT is ideal for regular round walks to check the temperature e.g. of cooling rooms or during incoming goods inspections.

The temperature and time data will be stored in the device and then transferred to the ebro® EDC software on a PC.

There it can be supplemented with additional data, e.g. personnel and locations, if required.

Reports and other evaluations can be made at any time.

This application of the ebro® HACCP system is ideal if it´s all about controlling the temperature and storing the data.

HACCP with TLC 750 BT and MyCCP

You can define the various HACCP tasks in MyCCP, whereupon the MyCCP app informs the responsible personnel.

If it´s cleaning the floor, washing the cutlery or the workwear – all can be entered, fulfilled and later checked. One of those tasks can be temperature control, and for that the TLC 750 BT is ideal.

The thermometer sends the measurement data to the app, which forwards it to the cloud.

This application of the ebro® HACCP system is ideal if it´s about the computer aided implementation of an HACCP concept, which includes temperature control,among other things.

Technical data

Measurement range -50 °C ... +250 °C (-58°F ... 482°F)

Accuracy infrared ±4 °C at -50 °C ... -30,1 °C (±7.2°F at -58°F...-22°F)

±2,5 °C at -30 °C ... -18,1 °C (±4.5°F at -22°F...-0.4°F)

±1,5 °C at -18 °C ... -0,1 °C (±2.7°F at -0.4°F...149°F)

±1,0 °C at 0 °C ... +65 °C (±1.8°F at 32°F...149°F)

±2,0 °C or 2 % at +65 °C ... +250 °C

(±3.6°F at 149°F...482°F)

Accuracy penetration probe ±0,5 °C at -30 °C ... +99.9 °C (±0.9°F at 22°F...212°F)

±1 °C (±2°F) or 1 % for the remaining

measurement range (whichever is larger)

Resolution 0,1 °C / 0.2°F

Distance: Spot ratio 8:1

Sensor Thermocouple type T

Operating temperature -20 °C ... +50 °C (-13°F ... 122°F)

Storage temperature -30 °C ... +70 °C (-40°F ... 158°F)

Battery Recharchable lithium polymer battery 3,7 V

Battery lifetime Approximately 8 h of continuous usw

Battery charging Wireless or via USB C port, 500mA

Dimensions (L x W x H) 169.5 x 44x23mm (without probe), needle

length = 100mm

Housing material ABS

Weight Approximately 140 g

Protection class IP 65

Automatic deactivation Automatically after 15 seconds, deactivatable

Certificate Factory Calibration Certificate

Memory capacity 200 Measurement values

Interfaces NFC (only TLC 750 NFC), BLE, USB-C
