All stainless steel hydraulic cylinders

Available in steel grades 1.4301/4305 (AISI 303/304) or 1.4401 (AISI 316).

Standard and customized models.

Our huge stock of standard parts and raw materials secures short lead times.

SR20 series, oil hydraulics:

• Double acting
• Piston diameters from 25 to 125 mm
• Rod diameters from 12 to 75 mm
• Strokes (diameter dependant) from 10 to 3000 mm in 1 mm increments.
• Work pressure 200 bar max.

SR11 series, oil hydraulics:

• Single acting "plungers"
• Tube inside diameters from 25 to 100 mm
• Rod diameters from 12 to 75 mm
• Strokes (diameter dependant) from 10 to 2000 mm in 1 mm increments.
• Work pressure 200 bar max.

AQ70 series, water hydraulics:

• Piston diameters from 25 to 100 mm
• Rod diameters from 12 to 60 mm
• Strokes (diameter dependant) from 10 to 3000 mm in 1 mm increments.
• Work pressure 140 bar max.

All stainless steel, pedal operated hydraulic pumps, with or without fluid reservoir.

Stainless steel grades 1.4301/4305 (AISI 304/303).

FT-3.5 series, 3,5 cc, single acting, dual outlet ports with check valves. Can operate two hydraulic cylinders.

FT-T series, 3,5 cc with (optinally sized) fluid reservoir/tank

Compact units combining a pedal operated pumps with a hydraulic cylinder and fluid reservoir. Available as both retracting/pulling and extracting/pushing cylinders.

Ideal for work platforms, worktables and small, mobile lifting units.

Easy-clean design in stainless steel. Easy to install.

FPC series, 3,5 cc pump and Ø32 mm pulling cylinder. Stroke-lengths from 50 to 400 mm.

FPCP series, 3,5 cc pump and Ø32 mm pushing cylinder. Stroke-lengths from 50 to 400 mm.

All stainless steel, manually operated valves for directional and flow control.

Ideal for small hydraulic systems (oil or water fluid) with flow rates <30 L/min and pressure <200 bar.

Directional valves, manually operated:

• NRV series, needle type, closed center, 4/3, 3/3 and 2/2 configurations

Flow control valves:

• FR1 series, needle type throttle valve
• FR1-KD series, needle type throttle valve with integrated check valve

Check valves:

PKV-06, pilot controlled check valve.
